Baseplates are available in carbon steel channel base, carbon steel baseplate with feet or stainless steel base-
plate with feet.
Table 10: Base Channel Dimensions for Figure 8
Carbon Steel
Channel Base
Carbon Steel
Baseplate
Stainless Steel
Baseplate
10 x 26
12 x 32
15 x 32
15 x 40
16 x 41
18 x 40
18 x 50
12 x 26
14.6 x 32
17 x 41
17 x 50
12 x 32
17 x 41
17 x 50
Centrifugal S200 Series Pump and Pedestal Weights
Figure 8 - Base Channel Dimensions for Pedestal Mounted Centrifugal Pumps
