SPX S2045 - Page 21

Table 12: Add Listed Weight for Legs
Motor Frame
Weight
lbs (kg)
143-213JM 10.5 (4.7)
215-254JM 12.5 (5.6)
254-326JM 42.5 (19.2)
Waukesha Cherry-Burrell Introduction
12/2010 95-03080 Page 21
Figure 9 - Close Coupled Pump
Table 11: Close Coupled Pump (Less Motor and Legs)
Motor
Frame
Pump Model
S2045
lbs (kg)
S2065LV
lbs (kg)
S2065
lbs (kg)
S2065HV
lbs (kg)
S2075
lbs (kg)
S2085LV
lbs (kg)
S2085
lbs (kg)
S2092
lbs (kg)
143-184JM
21
(9.5)
31
(14)
33
(14.9)
39
(17.7)
57
(25.8)
57
(25.8)
51
(23.1)
51
(23.1)
213-215JM
35
(15.8)
37
(16.7)
39
(17.6)
64
(29)
54
(24.4)
54
(24.4)
78
(35.3)
78
(35.3)
254-256JM
37
(16.7)
39
(17.6)
41
(18.5)
67
(30.4)
57
(25.8)
57
(25.8)
79
(35.8)
79
(35.8)
284-326JM
51
(23.1)
53
(24)
71
(32.2)
68
(30.8)
82
(37.1)
82
(37.1)
-- --
Add 5LB. For Pumps With Double Seals
Figure 10 - Legs
