SRAM Rockshox Recon Series User Manual

91
Lower Leg Installation
200 Hour Service Remove the old crush washer retainer and crush
washer from each bottom bolt.
Compress and hold the crush washer retainer with needle nose pliers
and unthread it, and the crush washer, from the bolt by turning the bolt
counter-clockwise.
Install a new crush washer retainer and crush washer onto each bolt.
NOTICE
Do not damage the bolt threads.
Do not reuse crush washers or crush washer retainers. Dirty or
damaged crush washers can cause oil to leak from the fork.
Install the hollow bottom bolt into the damper shaft, and install the solid
bottom bolt into the spring shaft.
Tighten each bolt.
5
5 mm Needle nose pliers
5 mm Needle nose pliers
6
5 mm
5 mm 7.3 N·m (65 in-lb)
5 mm
5 mm 7.3 N·m (65 in-lb)
