6-8
TRANSMISSION AND BRAKE SYSTEM
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
N: NEUTRAL POSITION
At this position, the engine does not transfer power to the
wheels and the vehicle will not move. However, for safety,
apply the brake while at rest.
To shift into
“D” or “R” from the “N” position after stop-
ping the vehicle, you have to depress the brake pedal.
• Never shift into “N” from the “D” position or vice versa when
the vehicle is moving, or the transmission will be damaged.
• If you have to stop on a hill and would like to use this neutral position,
depress the brake pedal firmly.
• Never attempt to move the gear selector lever to
“N” when the
vehicle is in motion.
WARNING
R: REVERSE POSITION
• Use this position to reverse the vehicle.
To shift into
“R” from “P” or “N”, completely stop the
vehicle and depress the brake pedal. When the shift lever
is in
“R” and parking aid system will be activated (optional*).
• Never shift into “R” when the vehicle is moving.
• Please note that the vehicle may slowly move rearward when the
selector lever is at
“R”.
WARNING
As a safety function, the gear selector lever cannot be moved into
“P” or “R” when the vehicle speed is above 7 ~ 10 km/h.
CAUTION
