LAMP
14-12
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1. Remove the ignition key from the key cylinder.
2. Cover the tip of a flat blade screwdriver with a cloth and
insert the tip into a lamp cover slot. Then, pry off the cover.
3. Replace the bulb with a new one.
4. Install the cover.
1. Remove the ignition key from the key cylinder.
2. Open the cover as shown in the figure.
3. Replace the bulb with a new one.
4. Install in the reverse order of removal.
GLOVE BOX LAMP DOOR COURTESY LAMP
C100_RHD_14-Lamp.p65 2006-05-16, ¿ÀÈÄ 8:3212
