INSTRUMENT CLUSTER
5-13
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
FRONT FOG LIGHT INDICATOR
When the tail or head lights are on, the fog lights come on
if the fog light switch is turned to the “ON” position. Then,
the fog light indicator in the instrument cluster comes on.
ENGINE OVERHEAT WARNING LIGHT
When the engine coolant temperate is abnormally hot, the
engine overheat warning light blinks and a warning buzzer
sounds. When this happens, stop the vehicle in a safe place
and let the engine cool down. For more information, refer to
Chapter 12 “When the engine is overheating.”
If you keep driving the vehicle with the warning light and buzzer
on, the engine can be damaged. After completely cooling down the
engine have an authorized dealer or service center check the
vehicle.
CAUTION
C100_RHD_05-Instrument Panel.p65 2006-05-16, ¿ÀÈÄ 8:2913
