SEAT BELT AND AIR BAG
8-4
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
SEAT BELT
SEAT BELT IN FRONT SEATS
Pretensioner (for Front Seat)*
When a severe frontal impact occurs, seat
belt pretensioners rewind the seat belts
immediately to restrain the occupants to
their seats. It helps the effective operation
of the seat belts and airbags.
Seat Belt Height Adjustment
• To raise the seat belt, slide the
seat belt height adjustor up.
• To lower the seat belt, press the
button and slide it down.
• Adjust the seat belt height before
driving.
• Shoulder belt should be positioned mid-
way over the shoulder, never across
the neck.
WARNING
Fastening the Seat Belt
• Insert the metal latch plate into the buckle
until it clicks.
• To unfasten the seat belt, press the but-
ton on the buckle.
C100_RHD_08-Seat Belt and Air Bag.p65 2006-05-16, ¿ÀÈÄ 8:304
