LAMP
14-6
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
FRONT FOG LIGHT
1. Remove the ignition key from the
key cylinder.
2. Remove the front fog light connec-
tor by pushing both locks in the
direction of the arrows.
3. Turn the bulb to remove it.
4. Replace it with a new one.
5. Install in the reverse order of
removal.
Front fog light
Front fog light
Because the front fog lights can be accessed
only from the bottom of the vehicle, it should
be done by a Ssangyong dealer or authorized
service operation.
CAUTION
Because the front fog lights can be accessed
only from the bottom of the vehicle, it should
be done by a Ssangyong dealer or authorized
service center.
CAUTION
C100_RHD_14-Lamp.p65 2006-05-16, ¿ÀÈÄ 8:326
