SEAT BELT AND AIR BAG
8-19
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
AIR BAG
The air bag Supplemental Restraint System (SRS) can provide additional protection for the
driver and passenger in the event of a collision.
Side Curtain Air Bag
The side curtain air bags are contained between
right above the front and rear doors and the end of
the vehicle roof. The side curtain air bag is designed
to inflate only in an impact to the side of the vehicle
and protect occupants’ heads.
Pretensioner (for Front Seat)*
When a severe frontal impact occurs, seat belt
pretensioners rewind the seat belts immediately to re-
strain the occupants to their seats. It helps the effective
operation of the seat belts and airbags.
If this lamp does not go out after engine starting or comes on while driving, it means that
there is a malfunction in the system. Have the air bag system checked immediately by a
Ssangyong Dealer or Ssangyong Authorized Service Center.
Air Bag Warning Light
Driver’s Air Bag
The driver’s air bag is
located at center of the
steering wheel.
Passenger’s Air Bag
The front passenger’s air
bag is located on the
dashboard.
C100_RHD_08-Seat Belt and Air Bag.p65 2006-05-16, ¿ÀÈÄ 8:3019
