LAMP
14-11
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
INTERIOR LAMPS
1. Remove the ignition key from the key cylinder.
2. Cover the tip of a flat blade screwdriver with a cloth and
insert the tip into a lamp cover slot. Then, pry off the cover.
3. Replace the bulb with a new one.
4. Install the cover.
1. Remove the ignition key from the key cylinder.
2. Cover the tip of a flat blade screwdriver with a cloth and
insert the tip into a lamp cover slot. Then, pry off the cover.
3. Replace the bulb with a new one.
4. Install the cover.
FRONT ROOM LAMP
CENTER ROOM AND LUGGAGE ROOM LAMPS
The cover should be pried up from the rear section (indicated by the
arrow). Otherwise, the cover may be damaged.
CAUTION
Center room
Luggage room lamps
C100_RHD_14-Lamp.p65 2006-05-16, ¿ÀÈÄ 8:3211
