ST STM32H7B3I-DK User Manual

1 Features
• STM32H7B3LIH6QU Arm
®
-based microcontroller featuring 2 Mbytes of Flash memory and 1.4 Mbyte of
RAM in BGA225 package
• 4.3" (480x272 pixels) TFT color LCD module including a capacitive touch panel with RGB interface
• Wi‑Fi
®
module compliant with 802.11 b/g/n
• USB OTG HS
• Audio codec
• 512-Mbit Octo-SPI NOR Flash memory
• 128-Mbit SDRAM
• 2 user LEDs
• User and Reset push-buttons
• Fanout daughterboard
• 1x FDCAN
• Board connectors:
– Camera (8 bit)
– USB with Micro-AB
– Stereo headset jack including analog microphone input
– Audio jack for external speakers
– microSD
™
card
– TAG-Connect 10-pin footprint
– Arm® Cortex® 10-pin 1.27mm-pitch debug connector over STDC14 footprint
– ARDUINO
®
Uno V3 expansion connector
– STMod+ expansion connector
– Audio daughterboard expansion connector
– External I
2
C expansion connector
• Flexible power-supply options:
– ST-LINK USB V
BUS
, USB OTG HS connector, or external sources
• On-board STLINK-V3E debugger/programmer with USB re-enumeration capability: mass storage, Virtual
COM port, and debug port
• Comprehensive free software libraries and examples available with the STM32Cube MCU Package
• Support of a wide choice of Integrated Development Environments (IDEs) including IAR
™
, Keil
®
, and GCC-
based IDEs
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
UM2569
Features
UM2569 - Rev 1
page 2/54
