Pin
number
Pin name
Onboard
peripheral signals
ARDUINO
®
signals
STMod+ signals
E4 PQ1 IMU_INT1 - -
E3 PQ2 IMU_INT2 - -
D3 PQ3 LCD_ON/OFF - -
D4 PQ4 LCD_INT - -
D5 PQ5 TOF_LPn - -
A2 PQ6 LCD_BL_CTRL - -
G5 PQ7 PWR_SD_EN - -
1.
ADC is in the 1.8 V power domain. I/O is in the 3.3 V power domain. For ADC pins in ARDUINO
®
and STMod+ connectors,
each pin is connected to two pins (
ADC and I/O) of the MCU.
2. P9 of the STMod+ connector misses the SPI feature. This is a limitation.
UM3300
STM32N6570-DK I/O assignment
UM3300 - Rev 1
page 36/49
