2 Ordering information
To order the NUCLEO-U575ZI-Q Nucleo-144 board, refer to Table 1. Additional information is available from the
datasheet and reference manual of the target STM32.
Table 1. Ordering information
Order code Board reference Target STM32
NUCLEO-U575ZI-Q MB1549 STM32U575ZIT6Q
2.1 Products and codification
The meaning of the codification is explained in Table 1.
Table 2. Codification explanation
NUCLEO-XXYYZE-Q Description Example: NUCLEO-U575ZI-Q
XX MCU series in STM32 Arm Cortex MCUs STM32U5 Series
YY MCU product line in the series STM32U575/585
Z STM32 package pin count 144 pins
E
STM32 Flash memory size:
• I for 2 Mbytes
• J for 4 Mbytes
2 Mbytes
-Q STM32 has an internal SMPS function SMPS
The order code is mentioned on a sticker placed on the top or bottom side of the board.
UM2861
Ordering information
UM2861 - Rev 2
page 3/49
