STM8 development tools AN2752
24/42 Doc ID 14651 Rev 3
Emulation system: STice
Emulator box
Cables for USB, power supply, trigger, analyzer input
Connection flex
60-pin or 120-pin cable for connection to the application board
Connection adapter
Links the connection flex to the footprint of the STM8S microcontroller
Adapter socket
Package-specific socket for connection adapter and STM8S microcontroller
8.2.2 STice in emulation configuration
In emulation configuration, the STice is connected to the PC via a USB interface and to the
application board in place of the target microcontroller being used.
Connection flex: Flexible cable (60-pin or 120-pin depending on the target
microcontroller) that relays signals from the STice to the application board
Connection adapter: Links the connection flex to the footprint of the target
microcontroller on the users application board.
Adapter socket: Socket that solders to the application board in place of the
microcontroller and receives the connection adapter.
The above accessories are not included with the STice system. To determine exactly what
is required for any supported microcontroller, refer to the online product selector on
www.st.com.
