– 13 –
ENGLISH
Note: When removing the ribbon
cartridge, raise the A section
and then remove it by hold-
ing the B section as shown in
Fig. 6-3.
6-1-2.Loading the paper
1 Lift the cover up approx. 3cm. Hold
the cover tilted at this angle, then
pull it toward you to remove it.
2 Cut off the front edge of the roll
paper perpendicularly.
3 Confirm that the power of the printer
is turned on.
Fig. 6-3 Removing the ribbon cartridge
Fig. 6-4 Removing the cover
A
B
Cover
