V01-2013 35mm-01 serie
14
HOW TO USE THE STEENBECK 35mm 01-SERIES. (continued)
5.6 connecting to mains power:
Connect the machine to the power network according to the instructions on page 5
with the supplied power cable. Make sure that this cable is well connected.
Always check the Voltage and Frequency mentioned on the type and serial number
plate (back side table).
Of great importance is a safe power ground system.
Switch the 01-Series on with the main switch fig.2 #14 page 10), it shows a green
light.(15)
Only then switch on the sub functions (from 16 onwards).
Warning : before switching off the table, always switch off all the sub functions.
5.7 Threading film:
Thread 35mm film according to pages 30 - 34
Attention: in order to prevent unnecessary wear, when threading film without sound,
never use the magnetic head (fig. 5 #50 page 11) and sprocket (37), and switch off
the sound (fig. 2 #16 page 10).
When the film has COMOPT sound, thread the film with sprocket (37) in a way the
tension roller (45) can move a little bit, this because too much tension can damage
the perforation.
Use the speed switch (fig 1 #6 page 9) to view the film.
While winding or rewinding from 0 to sync speed and sync, the speed is continuously
variable.
This makes it possible to view the film frame by frame.
When the framing is not correct it can be adjusted (see pages 25 - 28).
Focus picture is adjustable (fig.5 #41 page 11).
Thread the 35mm film according the version.
Pages 30 - 34 show the way to thread film with and without sound.
Also shown are the threading of SEPMAG / SEPOPT.
