Steenbeck 01 Series User Manual

V01-2013 35mm-01 serie
6
3.4 GENERAL DATA.
Power: 1 phase 100 – 240 Volts - 50 / 60 Hz.
Power consumption: approx. 800 – 1000 W. (depending on version)
Switch on current: 10 Amps. (at 230 V)
The fuses (5x20mm) 100 – 120 Volt 10 Amp T and 0,5 Amp T.
220 – 240 Volt 6,3 Amp T and 0,5 Amps T
The fuses can be found on the back side of the machine. (see fig. 4 page 10)
Important: all fuses in the Steenbeck 01-Series are T (slow blown) and
Should never be replaced by F (fast blown) fuses.
Sizes of a complete table incl. monitor and speakers:
ST3511 – ST(1)401; compact sized editors:
width 120 cm
working height 80 cm
depth, incl. monitor 99 cm
total height 129 cm
Weight 150 kg up to 160 kg.
ST701 – ST721; large sized editors:
width 152 cm
working height 80 cm
depth, incl. monitor 109 cm
total height 129 cm
Weight 200 kg up to 230 kg.
