V01-2013 35mm-01 serie
4
3.0 TECHNICAL DATA:
3.1 DRIVE SYSTEM.
3.1.1 Introduction:
The Steenbeck 01-Series has a proven 1 motor drive technology.
The table runs smoothly, because of the famous Steenbeck ‘speed switch’.
This speed switch has fixed points for sync (synchronous 24 of 25 frames per second
f.p.s.) forward and reverse, and adjustable notches between sync en maximum
speed. (approx. 50 f.p.s., forward and reverse selectable by user).
The maximum speed can also be adjusted to approx. 100 f.p.s.
The maximum for both directions can be a little different.
3.1.2 Film plates / cores:
Depending on version the film plates are for approx. 400 meter / 1300 feet of film up
to 600 meter / 2000 feet of film with cores/bobbins according to DIN 15531.
The winding tension of the plates can be adjusted.
3.1.3 Shrunken material:
The standard supplied sprocket rings are made to be used also for slightly shrunken
film material. If the film is in a bad condition (very stretched or shrunken) it is
advisable to change the sprocket ring at the polygon, otherwise the film can be
damaged.
For shrunken film with sound the COMOPT sprocket should also replaced by a
shrunken one.
We also have sprockets for shrunken SEPMAG perforated tape.
See options for the correct stock numbers in case of ordering.
3.1.4 Frictions:
The frictions are fitted with core holders for use of film cores.
It is recommended to use film bobbins/cores of 100mm diameter.
