V01-2013 35mm-01 serie
18
7.0 Connecting loudspeakers and (optional) working lamp:
All connections at the back of the frame.
Work light: (fig. )
Connector for 230V light max. 60 Watt.
The connection is as follows:
230 Volt: pin 1 = phase + / pin 2 = phase - / pin 3 = ground
ST701
