Cable & Hook Assembly - PN 57597
PN 57597
.YTQNOITPIRCSEDTRAPMETI
1 11545 SHEAVE 6620 6.75 DIA .31R/1.94 THK1
2 57596PC PLATE SNATCH BLOCK 5521 2
3 13436 PIN .38X4.00 QUICK RELEASE1
4 25831HOOK 5 TON SWIVEL CROSBY 10286231
5 9610WIRE ROPE 0.31 6X19 IWRC-XIP 90FT1
1RETTOC 60.4X00.1 NIPPZ478936
7 0867 MACHY WASHER 1.00ID 14GA2
200.2X57.0X44.0 RALLOCCP346448
9 0347 NUT 0.38-16 HHGR5 NYLOC 2
2HCNYL 65.1X91.0 NIP357501
1KOOH V GNIHSUB4489311
12 C6219 WASHER 0.75 SAE FLAT YELLOW GR82
13 5841 CAP SCR 0.75-10X4.50 HHGR8 1
14 C0538NUT 0.75-10 HHGR8 NYLOC1
15 0531 CAP SCR 0.38-16X3.50 HHGR5 2
