Wave User Guide
10
© 2017 Stenograph
9. Grasp the inner tripod tube with one hand and with the other hand, rotate the machine clockwise until
you hear a solid click. Ensure the Wave is firmly attached to the tripod tube.
Adjust the Tripod Height
1. Grasp the tripod tube firmly, directly beneath the Wave, with one hand.
2. Use your other hand to loosen the thumb-lock knob on the tripod. As you loosen the thumb-lock,
support the weight of the Wave with your hand.
3. Adjust the Wave to the desired height.
4. Tighten the thumb-lock knob.
Adjust the Tilting Screen
1. Gently pull up on the display and adjust the tilt as necessary.
2. To fold it flat, gently pull down on the display. When the Wave is On and the display is folded flat, the
display remains On.
Tilting the Wave
The Wave is constructed with a built-in recessed tilt mechanism. Once the Wave is secured on the
tripod, tilt the writing machine forward or backward within 10 degrees to a position comfortable for your
writing style.
To tilt the Wave:
1. Open the Tilting screen before adjusting the tilt position of the Wave.
2. Position one hand on the back of the Wave behind the Tilting screen and the other hand on the front
of the machine under the vowel keys.
3. Gently lift up or push down to the desired position. The movement of the Tilting mechanism is stiff to
ensure the position of the desired tilt is secure while writing.
Remove the Tripod
To remove the tripod, follow these steps:
1. Position the tripod firmly on the floor.
2. Locate the quick release lever on the left underside of the Wave.
3. Push the quick release lever towards the back of the Wave, then rotate the Wave counterclockwise
one quarter of a turn.
4. Lift the Wave from the tripod.
