47
EN
Data interface USB / Parallel (LPT1) / Network RJ-45
Input voltage AC 100 – 240 V
Output voltage DC 30 V
Power consumption 160 W
Property D�420 D�600 D�840
Weight [kg] 16,5 20 25,4
Dimensions (LxWxH) [mm] 600 x 443 x 546 776 x 591 x 546 1021 x 756 x 546
Workspace (L*xWxH**) [mm] 415 x 298 x 132 596 x 417 x 132 833 x 594 x 132
Clamping area (LxW) [mm] 499 x 316 679 x 436 920 x 616
Passage height HPL Table [mm] 140
Tool holder Ø 43 mm Euro Neck (optionally smaller diameters)
Driving stepper motors 2A Sanyo Denki® NEMA17
Axis resolution 1600 Steps / Revolution
Programmable resolution 0,001875 mm
Step mode
1
/
8
Stepping
Spindle igus dryspin®
Distance / rotation 3 mm / Revolution
Linear guide STEPCRAFT All Steel Motion
TM
Repeatability ± 0,04 mm ± 0,05 mm
Backlash < 0,08 mm adjustable < 0,1 mm adjustable
Shortest ramp / slope 300 ms
7 Technical Data
7�1 General Data
Max. speed diagonal XY 99
mm
/
s
Speed (fast) 70
mm
/
s
Speed (manual drive fast) X = 40
mm
/
s
, Y = 40
mm
/
s
, Z = 30
mm
/
s
Speed (reference drive search) X, Y, Z = 20
mm
/
s
Speed (manual slow) X, Y, Z = 4
mm
/
s
Speed (reference drive retract) X, Y, Z = 1
mm
/
s
