Modbus RS485 Stepper Drive User Manual
22
Reserved
Filter time setting
Bit15
Bit14
Bit13
Bit12
Bit11
Bit10
Bit9
Bit8
Reserved bit, write 0 by default
Register
Value
Filtering time (unit: ms)
0000
10
0001
1
0010
2
0011
3
0100
4
0101
5
0110
6
0111
8
1000
15
1001
20
1010
30
1011
40
1100
50
1101
100
1110
200
1111
500
Note:
(1) The values of the registers correspond to the individual
filter times. The default state is 0000, which correspond to
10ms
(2) If you need to set other filter times for the IO port, you can
fill in the value manually in the parameter manage table of
STEPPERONLINE MotionStudio.
Example 1: IO input port 1 is set to enable function. Normally closed. Filter time 50ms
The register value is configured as 0000 1100 1000 1000, which is converted to 3208 in decimal, i.e. write 3208 to
Pr4.02 to achieve the above configuration.
Example 2: IO input port 1 is set to enable function. Normally closed. Filter time 10ms (default)
The register value is configured as 0000 0000 1000 1000, which translates to 136 in decimal, i.e. write 136 to
Pr4.02 to achieve the above configuration.
Routine 3: IO input port 7 is set to JOG2 function. Normally open. Filter time 500ms
The register configuration is 0000 1111 0010 1100, which is converted to 3884 in decimal, i.e. write 3884 to Pr4.08
to achieve the above configuration.
4.3.4 Status Monitoring Parameters
Register address
Definition
Attribut
es
Unit
Description
0x1001
Control Mode
R
/
Invalid, always “0”
0x1003
Motion state
R
/
Bit0: 0--normally, 1--faulty;
Bit1: 0--drive disable, 1--enable;
Bit2: 0--not running, 1--running;
Bit4: 0-- Command not completed,
1-- Command completed;
Bit5: 0-- Path not completed,
1-- Path completed;
Bit6: 0--Homing not completed,
1--Homing completed.
0x1010 (high 16-bit)
0x1011 (low 16-bit)
Position following error
R
pulses
-
0x1012 (high 16-bit)
Profile position
R
pulses
-
