SPECTRE NANO OSDP
TM
© STid – MU_ULTRYS_V3.0.1_EN
Summary table
Note: as long as the action is detected on the input, the output remains toggled.
Reading mode
Input
Configurable
Outputs
states?
Maintain
during
detection
available?
Output
Relay
on
detection
Continuous reading without
using inputs
No action
Yes
Yes
- If ‘Continuing
during detection
process’ not
activated: the output
state toggles at the
ascent
- If ‘Continuing
during detection
process’ activated:
the output state
toggles to the RF
detection and
remains in this state
as long as, at each
scan is at least one
detection
Yes
Trigger of the reading by the
event (use of the input)
An action on
the input
activates
reading on the
lanel
Yes
Yes
Yes
b
