WIEGAND 3La
Message
Wiegand 32 bits identical to Wiegand 3Ca without the LRC.
The frame consists of 32 bits as follows:
Bit 1…Bit 32
Structure
Data (32 bits)
Description
8 hexadecimal digits
MSByte first
Example
For the hexadecimal code “0x001950C3”, the frame sent will be:
0000
0000
0001
1001
0101
0000
1100
0011
0
0
1
9
5
0
C
3
Digit 1
Digit 2
Digit 3
Digit 4
Digit 5
Digit 6
Digit 7
Digit 8
WIEGAND 3Lb
Message
Wiegand 40 bits identical to Wiegand 3Cb without the LRC.
The frame consists of 40 bits as follows:
Bit 1…Bit 40
Structure
Data (40 bits)
Description
10 hexadecimal digits
MSByte first
Example
For the hexadecimal code “0x 01001950C3”, the frame sent will be:
0000
0001
0000
0000
0001
1001
0101
0000
1100
0011
0
1
0
0
1
9
5
0
C
3
Digit 1
Digit 2
Digit 3
Digit 4
Digit 5
Digit 6
Digit 7
Digit 8
Digit 9
Digit 10
