Stid ultrys - Step 6- Light Indicator Configuration

208
SPECTRE ATX OSDP
TM
© STid – MU_ULTRYS_V3.0.1_EN
Summary table
Step 6- Light indicator configuration
The SPECTRE ATX reader is not equipped with an LED card or a Buzzer.
Step 6 does not exist in the SPECTRE ATX setup wizard.
Reading Mode
Input
Configurable
Outputs
states?
Output
Continuous
reading without
using inputs
No action
Yes
The output state toggles at
the ascent
Trigger of the
reading by the
event
An action on the
input activates
the reading on
the lane
Yes
The output state toggles at
the ascent during the
ascent time of the identifier
(physically on the BUS +
200ms
