WORKSHOP MANUAL
MP 84/98 - MP 84/98 Hy
For assembly follow the operations described a bo ve
in reverse order, making sure not to confuse the or der
of the screws (11) - (12) - (13) - (14) since:
– screws (11) - (13) - (14) have a stop that optimi ses
use for plastic components;
– screws (12) do not have stops and are suited for
metallic components.
Correctly reposition the wire sheath (15) in its hou sing
on the lower right-hand side of the dashboard.
– 2 lower side screws (13) (1 for each side) located
in side the engine compartment,
– 2 lower screws (14) (1 for each side) accessible af-
ter removing the central cover.
The dashboard (10) is held by:
– 2 upper frontal screws (11) inside the engine com -
partment,
– 2 lower frontal screws (12) (1 for each side) loca ted
inside the engine compartment,
REMOVAL OF THE DASHBOARD
CHAPTER REVISION FROM ... PAGE
5.4 1 2018 2 of 2
111011
12
13
14
1211 - 13 - 14
15
