WORKSHOP MANUAL
Map of functional units
MP 84/98 - MP 84/98 Hy
IMPORTANT! If the microswitches are to func
tion correctly, it is important to follow the exact assem
bly positions by re ferring to the drawings that indicate
the various usages of each type.
A = Free
B = Activated
General informations
Related topics
---
FITTING SAFETY MICROSWITCHES
CHAPTER REVISION FROM ... PAGE
7.10 0 2018 1 of 1
15 mm
A B
2 6 mm
min. 1 mm
A B
