WORKSHOP MANUAL
MP 84/98 - MP 84/98 Hy
RELATED TOPICS:
Adjustments and tuning
Adjusting the engagement and checking the blade brake ................... [
4.1]
Aligning the cutting deck ................................................................... [
4.5]
Checking blades alignment ................................................................ [
4.8]
Removing, sharpening and balancing the blades ............................... [
4.9]
Removal of external parts and main assemblies
Removal of the side guards (if provided) ......................................... [
5.2]
Removal of the cutting deck ............................................................... [
5.7]
Removal of the ejection conveyor ....................................................... [
5.8]
Repairs
Replacement of the blades control belt ............................................ [
6.6]
Replacement of the supports and shafts of the blades ....................... [
6.7]
Replacement of the lifting cable ......................................................... [
6.9]
General informations
The terms “Cutting deck” or “Equipment” refer to
the cuttingmeans assembly, connected to the
machine PTO by means of a belt.
Related topics
---
INDEX OF FUNCTIONAL UNITS
Cutting Deck
CHAPTER REVISION FROM ... PAGE
ii 0 2018 3 of 6
