WORKSHOP MANUAL
MP 84/98 - MP 84/98 Hy
Fully tighten the engine and pulley xing screws to the
prescribed values.
Remember to t the clamps back on the fuel
pipe and check that it does not leak.
Carefully restore all electric and earth contacts and al-
ways ret the exhaust guard (8).
Reattach the accelerator cable and ...
Adjust the «MINIMUM» position.
Ret the front hood.
For reassembly follow the operations described a bo-
ve in reverse.
If the spacer (7) is installed, it must be tted with the
counter-sinking hole facing the engine.
Ensure that the pin (9) is inserted in the groove in the
clutch (2) and remember to replace the spring (4).
Detach the fuel line pipe, taking care not to spill
fuel.
Identify and undo all the screws that fasten the
engine to the chassis, then carefully lift and remove
the engine using equipment suitable for the weight of
the engine (about 35-45 kg) and the designated lifting
points to guarantee safe working conditions.
NOTE Some engines are held with screws of dier
ent length and in dierent positions, so it is best to
label them so that no errors are made on reassembly.
REMOVAL OF THE ENGINE
CHAPTER REVISION FROM ... PAGE
5.5 2 2018 2 of 2
7
2
4
2
9
2
8
