Stihl MS 461 Manual

9MS 461, MS 461-R
3.2 Chain Drive, Chain Brake, Chain Tensioner
Condition Cause Remedy
Chain sprocket wears rapidly Chain not properly tensioned Tension chain as specified
Wrong chain pitch Fit chain of correct pitch
Insufficient chain lubrication Check chain lubrication
Saw chain stops under full load Clutch shoes badly worn Install new clutch
Clutch drum badly worn Install new clutch drum
Brake band blocked Check freedom of movement and
operation of brake band
Saw chain runs while engine is
idling
Engine idle speed too high Readjust idle speed screw LA
Clutch springs stretched Replace the clutch springs or install
new clutch
Clutch springs broken Replace the clutch springs
Saw chain does not stop
immediately when brake is
activated
Chain brake spring
stretched / broken
Fit new brake spring
Brake band
stretched / worn / broken
Fit new brake band
Clutch drum worn Install new clutch drum

Stihl MS 461 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Automatic oiling	Yes
Oil tank capacity	0.325 L
Fuel tank capacity	0.8 L
Engine displacement	76.5 cm³
Engine power	6 hp
Power source	Gasoline

Weight and Dimensions

Weight	6700 g
