DESIGNATION
1.1 Manufacturer KION KION
1.2 Model type LTX 70 LTX 80
1.3
Method of propulsion: battery, die-
sel, petrol, LPG, mains power
Battery Battery
1.4
Driving: manual, pedestrian, stand-
ing, seated, order picking
Seated Seated
Towing capacity
(1)
t 7
(1)
8
(1)
1.5 Load capacity Q t 0.15 0.15
1.7 Rated drawbar pull F N 1400 1600
1.9 Wheelbase y ±5 mm 1190 1190
WEIGHT LTX 70 LTX 80
2.1 Kerb weight (with cab) kg ±10% 1515 1515
2.2
Axle load without load, front/rear (with
cab)
kg ±10% 665/850
(2)
665/850
(2)
2.1 Kerb weight (without cab) kg ±10% 1260 1260
2.2
Axle load without load, front/rear (with-
out cab)
kg ±10% 550/710
(2)
550/710
(2)
2.2 Axle load with load, front/rear (with cab) kg ±10% 665/1000
(2)
665/1000
(2)
2.2
Axle load with load, front/rear (without
cab)
kg ±10% 550/860
(2)
550/860
(2)
WHEELS AND PNEUMATIC TYRES LTX 70 LTX 80
3.1
Tyres, front/rear (SE = CS supere-
lastic, P = pneumatic)
(3)
pneumatic
(SE optional)
(3)
pneumatic
(SE optional)
(3)
3.2 Tyre size, front 4.00–8/6 PR 4.00–8/6 PR
3.3 Tyre size, rear 4.00–8/6 PR 4.00–8/6 PR
3.5
Wheels, number front/rear (x = driv-
en)
1/2 x 1/2 x
3.6 Track width, front
b1
0
±5 mm 0 0
3.7 Track width, rear
b1
1
±5 mm 860 860
DIMENSIONS LTX 70 LTX 80
4.7 Overhead guard height (cab) h6 ±5 mm 2070 2070
4.8 Seat/stand-on platform height h7 ±5 mm 1020 1020
4.1
2
Tow coupling height
h1
0
±5 mm
a) 1285 b) 340 c)
395
a) 1285 b) 340 c)
395
4.1
3
Platform height, without load
h1
1
±5 mm 645 645
Technical specifications
6
Datasheet for the tow tractor
