4.1
6
Loading platform length (with and
without cab)
I3 ±5 mm 265/520 265/520
4.1
7
Rear overhang I5 ±5 mm 350 350
4.1
8
Loading platform width b9 ±5 mm 900 900
4.1
9
Overall length i1 ±5 mm 1830 1830
4.2
1
Overall width b1 ±5 mm 1000 1000
4.3
2
Ground clearance at centre of
wheelbase
m2 ±2 mm 135 135
4.3
5
Turning radius, front
Wa
F
±20
mm
1650 1650
Turning radius, rear
Wa
R
±20
mm
1115 1115
Minimum steering angle 180°
±20
mm
2765 2765
4.3
6
Minimum pivot point distance
b1
3
±20
mm
600 600
PERFORMANCE DATA LTX 70 LTX 80
5.1 Driving speed, with/without load
±5%
km/h
11/20 10/20
5.5
Tractive force, without load, 60 mi-
nute rating
N 1400 1600
5.6
Maximum tractive force, without
load, 5 minute rating
N 6250 6250
5.7
Climbing ability, with/without load,
30 minute rating
% See graph See graph
5.8
Maximum climbing ability, with/with-
out load, 5 minute rating
% See graph See graph
5.1
0
Service brake Hydraulic/electric Hydraulic/electric
DRIVE SYSTEM LTX 70 LTX 80
6.1 Traction motor, 60 minute rating kW AC 4.5 AC 4.5
6.3
Battery type in accordance with
DIN/EC
DIN 43531 (12 -
1998)
DIN 43531 (12 -
1998)
6.4
Battery voltage and nominal capacity
(5 h)
V/
Ah
48/375 48/375
6.5 Battery weight (±10%) kg ±10% 560 560
6.6
Energy consumption according to
VDI cycle (2012)
kW
h
±10% 4.71 4.98
Technical specifications
6
Datasheet for the tow tractor
