3. Accept the dialog screen using the OK button.
POSITool automatically reads a list of the devices connected from the
mailbox gateway and displays the inverters in POSITool. If the mailbox
gateway does not support the information on the devices connected, you
can update the list using the Scan address list and Scan address range
buttons.
The list displays the inverters with their EtherCAT address, the name of
the slave (as defined in the master), the equipment code from parameter
E120, the serial number and the type of inverter.
