Stonex S10 GNSS Receiver – User Manual 9
3. S10 standard accessories
3.1. Power supply
Batteries (P/N 30-350170)
The standard configuration contains two batteries with S/N, a slot for charging
the batteries (the battery charger) and one adaptor. The batteries are “Lithium-
Ion” battery (11.1V-3400mAH; 37.7Wh), they features a very high energy-to-
weight ratio respect to Ni-Cd or NiMh batteries, no memory effect and slow
self-discharge when it is not used.
Fig. 3.1 - Lithium-Ion battery
Charger + Adapter (P/N 30-350171 + 30-350072)
The charger can be used for both batteries simultaneously. The lights of the
charger shows if the battery is being charged (red light FULL) or if it is already
charged (green light FULL). Red light POWER shows if the charger is powered
on and there is also a light which turns on in case of too high temperature (red
light TEMP).
Fig. 3.2 - S10 charger and adaptor
