Stonex S10 GNSS Receiver – User Manual 40
 Mount the S10 on the pole (tripod cannot be used for this step of the
calibration) at a minimum height of 2 m
 Position MUST BE FIXED!
 Choose one ground point and use it for the whole operation (do not
move the receiver from the same point): vertical position and 4 tilted
positions, along 4 directions (East, South,West, North)
Click on Magnetic Bias Angle
Keep the pole vertical with the bubble well
centered. Click on Center Point
S10 automatically starts to save points
(10 totally); a beep is heard when
finished. The message “Incline point
collection done!” is displayed.
Click on Incline Point
to continue calibration.
