Stonex S980A GNSS Receiver – User Manual v1.0
26
sensor. The self-check results will be broadcasted in the process. Self-check
operation and results are as it follows:
When receiver is powered on, press power button and hold it until the receiver
voice broadcasts “power off”. Press it again until the receiver sounds a beep
and the speaker broadcasts “self-check”, which means the receiver starts to
operate the self-check procedure. New receiver is recommended to operate
self-check at least once.
In the process of self-check, each module inspection is followed by its
inspection results. If the module inspection passes, it will broadcast “OK” and
module’s led keeps on until the whole self-check is completed. If the module
inspection fails, it will broadcast current module inspection fail, module’s will
flash and buzzer sound until you restart the receiver. Self-check lasts for about
1 minute. If there is a self-check failure, please contact local dealer.
If every module indicator is lit with no flashing, and speaker broadcasts for all
the modules “OK” (such as “GPS self-check. OK.”), it means they work normally.
Receiver starts to work after the whole self-check is completed.
3.4.1 Receiver Selfcheck with Display touch
With the new Stonex S980A, through the display the user can perform the self-
check procedure
To start the selfcheck follow these steps:
From the Status window scroll to the left to open the Working Mode menu.
