STONEX S980A - Positioning Accuracy; Integrated GNSS Antenna; Internal Radio

Stonex S980A GNSS Receiver – User Manual v1.0
49
POSITIONING
1
STATIC GNSS SURVEYING
High Precision Static Horizontal
2.5 mm + 0.1 ppm RMS
High Precision Static Vertical
3.5 mm + 0.4 ppm RMS
Static and Fast Static Horizontal
3 mm + 0.5 ppm RMS
Static and Fast Static Vertical
5 mm + 0.5 ppm RMS
CODE DIFFERENTIAL POSITIONING
Accuracy
0.40 m RMS
SBAS POSITIONING
2
Accuracy
0.60 m RMS
REAL TIME KINEMATIC (< 30 Km) – NETWORK RTK³
Fixed RTK Horizontal
5 mm + 1 ppm RMS
Fixed RTK Vertical
10 mm + 1 ppm RMS
RTK Signal Initialization
2 to 8 seconds
INTEGRATED GNSS ANTENNA
High accuracy four constellation micro-strip antenna, zero phase center, with internal multipath
suppressive board
INTERNAL RADIO 2-5 WATT
Type
Tx - Rx
Frequency range
410 – 470 MHz
Channel Spacing
12.5 KHz / 25 KHz
Range
5 Km in urban environment
Up to 15 Km with optimal conditions
4
