Page 12 Strand 200 Console Manual
Setup
Note: The power supplies are pack in the side of the packing material.
Plug the appropriate power adaptor into the console
where shown. Plug the male end into the
appropriate electrical service.
Plug the DMX
DMX device) into the DMX
Turn the console on via the rocker switch on the back plate and
the console is ready to go!
The 200 console will go through a self-test and return to the last known state.
512 cable from the dimmer rack (or any
512 output of the 200 console.
