Strand 200 Console Manual Page 11
DMX Output – accepts a DMX512 5 pin XLR connector from the dimmers or any other DMX
device.
Audio Input – allows a fader to control the audio trigger threshold from an audio source
connected to the console.
MIDI Input – allows an external source to control the triggering of effects from the console.
(MIDI stands for Musical Instrument Digital Interface)
MIDI Thru – allows the in-line connection of the console from one MIDI source to another.
Power Connector – accepts the power adaptor from the power transformer.
Console Power Switch – rocker switch to turn power to the console on and off.
Compact Flash Slot – allows for saving of shows onto a compact flash card. Only a 32M
compact flash card can be used. The compact flash card has to be dedicated to the 200
console. It cannot share with other devices due to a different file format. The show file
cannot be read on a standard PC.
Video Display Card (optional) – allows for the addition of a video display card for a display
monitor.
Terminology Notes
It is easy to confuse the terms of scenes and submasters. The following information will help
clarify…
Submasters – faders that contain cues or looks that are played back manually.
Scenes – faders that contain cues or looks that are played back via the playback faders.
All
levels recorded into scenes will be controlled by the submaster of the same number.
