Strand 200 Console Manual Page 27
Delete Effect
Page: #
Esc (+/-) Confirm
Delete an Effect Page
Num lock LED will now be on and the effect disabled.
Pick the effect page number.
Press Confirm to delete. Select YES or NO.
After confirming, it will return to the same screen but will the next available effect shown.
Repeat above process to make changes and delete. Pressing Esc will return to main display.
Inserting an Effect Step
A step can be inserted into an existing effect. Press the record key, the
“record” LED will light up indicating the console is now in record mode
and ready. Select the effect to be edited (the corresponding yellow LED
will start flashing). Press the + and – keys together for 1.5 seconds, the
effects address will start flashing.
Press + or – to change to the step to be inserted in front of, then record the new step using
the normal step record procedure. After recording the effect LED will stop flashing. Press
the record key to exit the record mode.
