Page 34 Strand 200 Console Manual
1. Edit patch
2. Display patch
3. Default patch
Esc Next Confirm
Turn on default
Patch?
Yes No
4. Unpatch all
Esc Next Confirm
Unpatch the
patch table?
Yes No
Default Patch
This will default all patch information back to a one to one status.
Notice the cursor flashing over the 1 for edit patch.
Press the right arrow key to access default patch
then press F3 to Confirm.
Press F2 for Yes or F3 for No.
Unpatch Patch
This will unpatch all dimmer (output) information.
Notice the cursor flashing over the 4 for unpatch all.
Press F3 to Confirm.
Press F2 for Yes or F3 for No.
Note: This will unpatch all dimmers (outputs).
If lights are on at the console, all stage lights will go out.
Note: This can be a very useful way to patch a show.
Start by unpatching all dimmers (outputs), then patch the dimmers to the channels that are needed
for the show.
Additional Information for Patch
Multiple Channel Patch Matrix
A powerful feature of this console is the ability to have any dimmer patched to multiple
channels at once. This allows scenarios like patching a dimmer to a channel to act as a
special. Then patching the same dimmer to a different channel at a proportional level to be
part of a wash.
