4 Site Requirements
Thefollowingfactorsshouldbeconsideredwhenchoosingasuitable
locationfortheprinterandserverworkstation:
•Isolationfromsou
rcesofvibrationsuchasgeneratorsandcentral
air‐
conditioningsystems.
•Protectionagainstsprinklersorpipescarryingli
quidsabovethe
system.
•Adequatefreespaceatthefrontoftheprintertoensureconven
ient
accessforloadingmaterialsandremovingprintedmodels.
4.1 Floor Area
Forconvenience,Stratasys recommendsthat you place the printeronastable
tableorstandwithlockablewheels.
YoucanorderaprinterstandfromStratasysusingpartnumber: OBJ‐0400
5.
Innormaloperation,theprinterrequiresaclearspaceof20cmbehindit.
Figure4–1isasamp
lefloorplan,showingthespacerequiredforthe
systemunitsandtheminim
umrecommen
dedserviceareafortheprinter.
Figure 4–1 Floor plan (minimum maintenance distances shown)
9'10"
300 cm
9'10"
300 cm
60 cm
Printer
24"
See Section 4.4
24"
60 cm
24"
60 cm
Service
Area
24"
60 cm
Server
Workstation
Switchbox
