Objet Desktop 3-D Printer Site Preparation Guide
DOC-04002 14 Rev. D2
Thefollowingwalloutletsarerequired:
•Onewalloutletbehindtheprinter(fortheprinter)
This shouldbeconnect
eddirectlytothemainelectricalpanel.
•Thre
ewalloutletsclosetotheprinter(fortheprinter‐
server
workstation,themonitor,andanextraoneforservicing
requirements)
5.2 Uninterruptible Power Supply (UPS)
Toavoidprintingproblemsduetopoweroutagesandotherpower
problems,itisrecommendedthatthecustomerinstallequipmentthat
ensuresacontinuouspowersupply,withthefollowingfunctionalityand
specifications.
5.2.1 Functionality
ThedeviceusedmusthaveaUSBalertoutputfor“gracefulsystem
shutdown.”(DonotuseaUPSdevicewhichonlyhasaSerialComsignal
output—RS‐232Protocol.)
5.2.2 Specifications
RefertotherelevantvoltagebelowwhenselectingaUPS:
5.3 Communication Lines
Atelephoneline,forgeneralcommunicationandservicecalls,is
recommendednearthesystem(incloseproximitytotheprinter).
Voltage Current Power
100–120 VAC, 50–60 Hz 16 Amps 1500 VA for 20 minutes
200–240 VAC, 50–60 Hz 8 Amps 1500 VA for 20 minutes
Table 5: UPS requirements
To provide adequate protection if a power failure occurs, the UPS requirements
are calculated to supply about 20% more than the printer’s power rating, shown in
section 5.1.1 on page 13, for the estimated time it may take to shut your system
down in a controlled manner. The UPS device recommended is not intended to let
you continue working.
