2.5 Installing the batteries
Fig.4
Open the cover on the remote control and insert 2x AAA type batteries into the compartment. Observe
correct polarity of the batteries when inserting. A terminal diagram is shown inside the compartment.
1. Remove the cover.
2. Insert the batteries.
3. Place the cover.
2.6 Using the remote control
Fig.5
To use the remote control, point it towards the front of your receiver. The remote control supports a
range of up to 5 meters distance to the receiver at an angle of up to approx. 30 degrees.
NOTE: Managing the receiver will be limited or not possible if there are obstacles
between the remote control sensor (at the front panel of the receiver) and
the remote control. Direct sunlight or very bright light can reduce or disturb
the reception of the remote control signals.
3.0 CONNECTION
3.1 Connecting to a terrestrial antenna
Fig.6
To receive broadcast signals, your terrestrial indoor or outdoor antenna must be connected to the ANT IN
connector on the back of the receiver. Use a proper shielded antenna cable and suitable connectors.
NOTE: If the signals at your location are too weak to receive proper signals with
an indoor antenna, we recommend using an outdoor antenna which
can be pointed towards the transmission tower. Ask your local dealer for
more information. If you are using an active antenna with built-in antenna
amplier, switch the antenna power to ON in the menu Antenna Power.
3.2 Connecting to TV with HDMI cable
Fig.7
The TV set shall be connected to the receiver using a good quality HDMI cable. This connection gives the
highest possible picture quality.
3.3 Connecting to TV with SCART cable
Fig.7
Your receiver is also equipped with a SCART connector; alternatively, the TV set can be connected to the
receiver using a good quality SCART cable.
6
