PART 2 • English
English
2.0 YOUR RECEIVER
2.1 Default PIN code: 1234
2.2 Front panel
Fig. 1
1. Smartcard reader Built in Conax smartcard reader for encrypted
channels with Conax smartcard and valid
subscription.* Insert smartcard with the chip side
down.
2. Power button: Turn ON from standby, and turn OFF to standby
mode
3. pq: Viewing mode: switch channel up/down.
Menu mode: for navigation
*The Conax smartcard and subscription are not part of this set-top box.
2.3 Rear Panel
Fig. 2
1. ANT IN To connect an antenna for reception of broadcasting
signal
2. TO TV To connect a TV set
3. SPDIF coaxial To connect to digital audio amplifier
4. HDMI To connect receiver to your TV set using an HDMI
cable
5. TV SCART To connect receiver to your TV set using a SCART
cable
6. VIDEO (RCA) To connect to the RCA video input of your TV or VCR
using an RCA cable
7. AUDIO (L/R) To connect to the audio input of your HIFI or
television
8. USB device To connect an external storage device
9. Power cable To connect the receiver to your main power supply
2.4 CA Interface
Although some TV and radio services are free-to-air, others are only available on a subscription basis
and can only be received via a Conditional Access component.
Inserting a CA card
Fig. 3
It is suitable for Conax coding system.
1. Open the right-hand flap on the front panel of the product to access the card slot.
2. Insert the CA card into the slot. Insert the smartcard with the chip side down.
