Specifications 47
7 Specifications*
Model:
5920-011-000 SmartPump Dual Channel Tourniquet Pump
Size:
Dimensions: 15.5 inch height x 10 inch width x 9 inch depth [39.4cm x 25.4cm x 22.9cm];
add 1.5 inch [3.8cm] for mounting pole at bottom;
1 inch [2.54cm] diameter roll stand pole mount
Weight:
Unpackaged: 12.0 lbs [5.45 kgs]
Packaged: 18.25 lbs [8.28 kgs]
Equipment Type:
Class I, Defibrillation Proof Type BF Applied Part
Approvals
CAN/CSA C22.2 No. 601.1
UL 60601-1
IEC 60601-1-2:2001 using IEC 61000-4-2, -3, -4, -5, -6, -8, -11;
EN61000-3-2, -3; EN55011 level A/ CISPR 11 A emissions
Power Sources:
AC Input: 100 - 240 VAC 50/60 Hz universal switching power supply
Automatic internal battery switchover for AC–free use or AC loss protection
Facility power: 120 VAC, 10A, hospital grade receptacle
AC Input:
Input voltage range: 100 – 240 VAC
Frequency: 50/60 Hz
AC fuses: 3.15A / 250V
Power requirements: 1.5 A @ 120 VAC
Internal DC Supply Module:
Output voltage: 15 VDC ± 1%, 150 mV pk-pk ripple
Output current: 4A maximum
Output power: 60 W maximum
Overload protection: short circuit, 110% - 150% auto recovery
Over voltage protection: 115% - 130% of rated output voltage
Internal Battery:
Type: nickel metal hydride (NiMH)
Nominal voltage: 12 VDC
Rated capacity: 2.6 Ahr
Over current protection: integral PTC fuse
Over temperature sense: integral thermistor
Charge time: 1 hour (80% charge), 6 hours (full charge)
Power conservation: 30 days (fully charged, then unplugged)
Display:
Type: High resolution backlit custom LCD
Timer: Elapsed time numeric
Pressure: Real-time digital numeric with graphic pressure gauge
*Specifications are approximate and may vary from unit to unit or as a result of power supply fluctuations.
