Stryker Visum - Illumination Specifications

34
S
10.3 Shipping Conditions
Shipping Humidity Shipping Temperature
Visum Blade LED Surgical Light*
10 – 95%
-40° – 131°F (-40 – 55°C)
Visum Blade LED Suspension*
-40° – 158°F (-40 – 70°C)
HD Camera
StrykeCam 2 Camera -40–140°F (-40–60°C)
* Individual system components may have less stringent shipping conditions. See shipping label for
component-specic shipping conditions.
10.4 Electrical Specications
Rated Input Voltage 100 -240V ~50/60Hz
Current 6A
Power per Light Head 259 - 416 Btu/hr (76 - 122 W)
10.5 Mechanical Specications
Force Required to Move Light Up to 25 N
Load Capacity of Light Spring Arm 95-176 Nm
Degrees of rotation at Spring Arm -
Light Head Joint
Unlimited (uninterrupted rotation)
Degrees of rotation at shoulder and
elbow joints for light Spring Arm
Unlimited (uninterrupted rotation)
Degrees of rotation at Cardanic Light
Head joint
260° ± 10°
Degrees of rotation at the shoulder
joint for at panel arms
Up to 320°
Degrees of rotation at the elbow joint
at at panel arms
Up to 310°
10.6 Illumination Specications
Central Illuminance (at 915mm from light) Up to 160,000 Lux
Light Field Diameter (d10 at 915mm) ≥7.5 in (190mm)
Depth of Illumination (20%) 36.8 in (935 mm)
Depth of Illumination (60%) 17.9 in (454mm)
Light Field Diameter (d50 at 915mm) ≥4.2in (107mm)
Color Temperature
4500K ± 500K
Color Rendering Index
≥90
R9 Rendering Index
88±10
Total Irradiance at Maximum Intensity
≤650 W/m
2
*
Ratio of Irradiation to Illuminance
≤4 mW/m
2
x Lux
LED Lifetime** (L70)
≥35,000 hrs
* Use caution when using multiple overlapping elds during surgical procedures to avoid
