wound drying. Do not overlap more than two light elds when lights are at maximum
illumination setting.
** LED light output: To remain at or above 70% initial output.
Estimate based on LED manufacturer data.
Shadow Dilution
with 1 shadow caster 77% ±10%
with 2 shadow casters 47% ±10%
with 1 tube 92% ±5%
with 1 tube and shadow caster 69% ±10%
with 1 tube and 2 shadow casters 43% ±10%
10.7 HD Camera Specications
Image Sensor 1/2.8 Type EXMOR CMOS Sensor
Picture Resolution Full HD 1080p (1920 x 1080) approx. 2,000,000 Active Pixels
Aspect Ratio 16:9
Lens 20x Optical Zoom, F=4.7mm (wide end) ~ 94.0mm (tele end F1.6 to F3.5) 4x
Digital Zoom
Horizontal Angle of View Includes 55.4° (wide end) to 2.9° (tele end)
Minimum Object Distance 10mm (wide end) ~ 1,000mm (tele end)
Minimum Illumination Less than 1.7 LX (F1.6, 50 IRE)
Signal-to-Noise Ratio (S/N) More than 50 DB
White Balance One-Push
Focus Automatic/Manual
Automatic Electronic Shutter Yes
Iris Control Automatic/Manual
Signal Output DVI 1080P60
Decoder Box Dimensions 8.66" W x 2.25" H x 6.88" D
10.7.1 HD Camera Components
Stryker P/N Description
P22338 Camera Assembly
P22059 Decoder Assembly
P22062 Decoder Wall Mount
