5.3.2 Wall Control Panel (Optional Accessory)
Light Controls
6
5
n
3
4
1
2
1. Selects the light(s) being controlled
2. Powers the selected light(s) on and o
3. Indicates the current brightness of lights
4. Adjusts the brightness of the selected light(s)
5. Indicates which light(s) is (are) selected
6. Controls the Camera (if that optional equipment is
connected)
The Select button selects one light at a time or all lights together.
• Each time the Select button is pushed, one light will be selected in succession.
• After each light has been individually selected, pushing the button again selects all of the lights.
The Power button switches on or o the selected lights.
• To turn on all lights, select all lights and press Power.
• To turn on one light, select that light and press Power.
• When one or more lights are already on and you want to turn on the remaining lights, select all
lights and press Power.
• When one or more lights are already on and you want to turn on just one more light, select that
light and press the Power button.
• To turn one light o when one or more lights are on, select that light and press the Power button.
• To turn o all lights when all lights are on, select all lights and press Power.
Note: You may either select any light individually or all lights together. To turn on any
other combination of lights you may want, you must select each light individually and
turn on one at a time.
The Brightness buttons increase or decrease the intensity of the selected lights incrementally.
